Speaker type 2-way, Acoustic suspension
Frequency range (-10dB) 56Hz - 20kHz (Half-space:2π)
Components LF 6.5" Cone
HF 0.75" Soft dome
Power rating NOISE 75W
PGM 150W
PEAK 300W
Nominal impedance 8Ω
SPL Sensitivity (1W; 1m on axis) 86dB SPL (Half-space:2π)
Peak (Calculated) 111dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
I/O connectors 1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
Dimensions D 205mm (8.1")
Net weight 4.4kg (9.7lbs)
Finish VXC6: Black / VXC6W: White
Accessories O-ring, Tile Rail, Cutout Template
Transformer taps 100V 60W (170Ω), 30W (330Ω), 15W (670Ω)
70V 60W (83Ω), 30W (170Ω), 15W (330Ω), 7.5W (670Ω)
Nominal coverage 110° conical (Half-space:2π)
Dimensions Diameter 286mm (11.3")
Cutout size Ø247 mm (Ø9-3/4")
Required ceiling board thickness 5 mm – 35 mm
Packaging Packaged in pairs
Certificate UL1480, UL2043, NFPA70, CE, EAC, RoHS
EN54-24 compliance -
